Introduction
This user guide contains information about the Extron FOX Tx/Rx AV family of signal transmitters
and receivers, with information on how to install and operate these units.
In this guide, unless otherwise specified, the terms “FOX Tx/Rx AV” and “FOX AV” refer to the
features or operation of all four units. The terms “FOX Tx AV” and “transmitter” refer to both the
multimode (MM) and singlemode (SM) transmitters and “FOX Rx AV” or “receiver” refer to both
the MM and SM receivers.
About the FOX Tx/Rx AV
The FOX Tx AV and FOX Rx AV are a high performance, low resolution video, audio, and data
(RS-232) transmitter (Tx) and receiver (Rx) pairs. Signals are transmitted over fiber optic cable at
rates up to 2 Gbps.
There are four different units:
• FOX Tx AV MM (multimode transmitter)
• FOX Tx AV SM (singlemode transmitter)
• FOX Rx AV MM (multimode receiver)
• FOX Rx AV SM (singlemode receiver)
The MM models have 850 nm multimode small form-factor pluggable (SFP) modules and carry
signals up to 2 km (6562feet). The SM models have 1310 nm singlemode SFP modules and
carry signals up to 30 km (18.6 miles). The transmitter is connected to the receiver using the
appropriate fiber optic cable (SM or MM).
WARNING:
AVERTISSEMENT :
• The FOX Tx/Rx AV outputs continuous invisible light (Class 1 rated), which may be
harmful and dangerous to the eyes; use with caution.
• Le FOX Tx/Rx AV émet une lumière invisible en continu (conforme à la classe1) qui
peut être dangereux pour les yeux, à utiliser avec précaution.
• Do not look into the rear panel fiber optic cable connectors or into the fiber optic
cables themselves.
• Ne regardez pas dans les connecteurs de câble fibre optique sur le panneau arrière
ou dans les câbles fibre optique eux-mêmes.
NOTES:
• The transmitter and receiver must be compatible. Both must be MM or both must be
SM. It is not possible to mix types.
• Plug the attached dust caps into the optical transceivers when the fiber optic cable is
unplugged.
FOX Tx/Rx AV • Introduction 1
