DTP2 T 202 FB • Introduction 2
L
RS-232 IR
Tx Rx Tx RxG
R
POWER
12V
--A MAX
AUDIO
OUTPUTS
OVER DTP2
SIG LINK
DTP2 IN
IN1808 IPCP MA 70
INPUTS (DTP2/XTP)
LOOP OUT
31
2
5
4 6
7
SIG LINK
IN
8
SIG LINK
IN
OUTPUTS (DTP2/XTP/HDBT) AUDIO INPUTS OUTPUTS REMOTE
HDMI/CEC
OVER TP
1A 1B
SIG LINK
OUT
Tx Rx
IR
G
LAN
AV LAN 2
AV LAN 3
AV LAN 1
Tx Rx
RTS CTS
G
Tx Rx G Tx Rx G
R
1 2 3 4 G
DIGITAL I/OCOM 3COM 2COM 1
S SG G
1
1
2
2
C 3 4 C
-S G+S+V
PWR OUT = 6W
RRRRRRRRRR
R
R
R
R
R
R
R
R
R
R
R
R
R
IR/SERIAL eBUSRELAYS
100-240V 50/60 Hz
--A MAX
Tx Rx
RS-232
G
RESET
1 2
3 4
+48V
+48V
1
2
MIC/LINE
L R
AUX
3 4
AMPLIFIED OUTPUT
70V - 100W
CLASS 2 WIRING
MODEL 80
FLAT PANEL
MODEL 80
FLAT PANEL
1
WiFi
1 2 3 4
WiFi
1 2 3 4
HDMI IN
AUDIO IN
DTP2 T 202 FB
DISPLAY PORT IN
HDMI IN
AUDIO IN
HDMI
DP
SIG
HDCP
AUTO
CONFIG
RESET
OUT
Extron
IN1808 IPCP MA 70
Seamless
Presentation
Scaler
Extron
DTP2 R 211
Receiver
Extron
DTP T HWP
4K 331 D
Transmitter
Extron
TLP Pro 1025T
Tabletop
Touchpanel
Extron
FF 220T
Plenum 2' x 2' Flat Field
Ceiling Speakers
Ethernet
HDMI
DisplayPort HDMI
HDMI
HDMI
4K Display
4K Display
PC PC
4K Media Player
Extron
DTP2 T 202 FB
Transmit ter
CATx Cable
up to 330' (100 m)
CATx Cable
up to 330' (100 m)
CATx Cable
up to 330' (100 m)
AV
LAN
Ethernet
RS-232
AV
LAN
Audio
Handheld
Microphones
Figure 1. Typical Switching Transmitter Application
The switching transmitters are controlled by Simple Instruction Set (SIS) commands (see
Simple Instruction Set Control on page 21) and the Extron Product Configuration
Software (see Product Configuration Software on page 28).
Control Communications
The RS-232 and IR communications are passive pass-through only. The receiver and
transmitter do not generate or respond to the RS-232 and IR communication signals.
HDCP, EDID and CEC are negotiated from source to sink, with the receiver and transmitter
transparent during the exchange.
TP Cable Advantages
Twisted pair cable is much smaller, lighter, more flexible, and less expensive than coaxial
or HDMI cable. These receiver and transmitter twisted pair (TP) products make cable runs
simpler and less cumbersome. Termination of the cable with RJ-45 connectors is simple,
quick, and economical.
NOTE: Do not use Extron UTP23SF-4 Enhanced Skew-Free AV UTP cable or STP201
cable to link the receiver and transmitter. DTP2 and legacy DTP receivers and
transmitters do not work properly with these cables.
