Extron DTP T UWP 4K D Series • Remote Control 15
Symbol definitions
]
= Carriage return/line feed
}
= Carriage return (no line feed)
| = Pipe (can be used interchangeably with the
}
character)
• = Space
E
= Escape key
W = Can be used interchangeably with the
E
character
X! = Input number 0
through
2
(
0
= deselect input [break tie]. This results in the output being disabled.)
1 = HDMI, 2 = VGA
X@ = Auto switch mode 0 = disabled (default)
1 = enabled (highest active input has priority)
2 = enabled (lowest active input has priority)
X# = Video mute 0 = Unmute video and sync (default)
1 = Mute video to black screen while sync is on
2 = Mute video and sync
X$ = Output 5V mode 0 = Auto (5V enabled when source with 5V present, else off)
1 = 5V always enabled (default)
X^ = Output format HDMI Port: 0 = Force output to DVI format, 1 = HDMI out if HDMI sink; DVI if DVI sink,
2 = Follow input format (default)
VGA Port: 0 = Force output to DVI format (default), 1 = HDMI out if HDMI sink; DVI if
DVI sink
X& = TMDS pass-thru mode 0 = off
1 = on
2 = auto (default)
X( = Status 0 = off, disabled, or not detected
1 = on, enabled, or detected
X1! = Input HDCP status 0 = No source is detected
1 = Source is detected with HDCP
2 = Source detected without HDCP
X1@ = Output HDCP status 0 = No sink is detected
1 = Sink is detected with HDCP support
2 = Sink is detected without HDCP support
X1# = Transmitter name A text string of up to 24 alphanumeric characters and minus sign or hyphen (-).
No blank or space characters are permitted as part of a name. The first character must
be a letter, and the last character must not be a minus sign or hyphen (default is
DTP-T-UWP-4K-232-D-[COLOR] or DTP-T-UWP-4K-332-D-[COLOR]).
X1$ = Raw EDID data 128 or 256 bytes of hexadecimal data
X1% = Video color bit depth mode 0 = Auto (default, based on sink EDID)
1 = force 8-bit
X1^ = Current EDID native resolution and refresh rate in plain text
X1& = Verbose mode 0 = clear/none
1 = verbose mode (default)
2 = tagged responses for queries
3 = verbose mode and tagged for queries
X1* = Input audio format HDMI: 0 = embedded digital audio, 1 = analog audio input,
2 = auto select (embedded digital audio takes priority)
VGA Port: 0 = disable analog audio embedding, 1 = enable analog audio embedding
X1( = Pixel phase value 0 to 63, default is 32
X2) = Total pixels value ±255 of default value (depends on input rate)
X2! = Horizontal and vertical start value 0 to 255 (default is 128)
