Extron DTP T HD2 4K 230/330 • SIS Commands 17
Command ASCII Command
(host to unit)
Response
(unit to host)
Additional Description
EDID Minder
Assign EDID to input
EAX$EDID} EdidAX$] X$ = EDID memory location (1-16)
see the DTP T HD2 4K EDID
Memory Locations table on page 14
(default is 9)
View EDID assignment
EAEDID}
X$]
EdidAX$]
Verbose Mode 2/3
Save EDID of output to
user location
ESX!*X$EDID} EdidSX!*X$]
Store the EDID of output X! into EDID
memory location X$ (58 or 59)
View/Read EDID in Hex
EREDID}
X%]
EdidRX%
Display currently assigned EDID in
Hex
Verbose 2/3
View EDID native
resolution
ENEDID}
X^]
EdidNX^
Resolution and refresh rate of
currently selected EDID
Verbose Mode 2/3
Example: 1600x1200@60Hz
Unit Name
Set unit name
EX*CN} Ipn•X*]
X* = Up to 24 alphanumeric
characters, including "-"
Set unit name to factory
default
E•CN} Ipn•{Default}]
Example:
DTP-T-HD2-330
(Model name)
View unit name
ECN}
X*]
Ipn•X*]
Verbose Mode 2/3
Other
Set verbose mode
EX1#CV} VrbX1#] 0-3 (1 is default)
Query verbose mode
ECV}
X1#]
VrbX1#]
Verbose Mode 2/3
Query DTP mode
EO1HDBT} X1@]
HdbtOX1@]
Verbose Mode 2/3
Request part number
N/n 60-1491-12]
60-1491-52]
DTP T HD2 4K 230
DTP T HD2 4K 330
Query firmware version
Q/q
X&]
Query firmware version
with build
*Q/q x.xx.xxxx]
Firmware build with 2 decimals
Reset settings
EZXXX} Zpx]
NOTES:
X! = Output selection
X$ = EDID memory location
X% = EDID data as 256 bytes of hex data (text representation)
X^ = Native resolution and refresh rate (translated from hex)
X* = Unit name
X1@ = DTP/HDBaseT switch position
X1# = Verbose mode
1
through max number of outputs
1-16
(9 is default), see table on page 14
Example: 1600x1200@60Hz
Up to 24 alphanumeric characters (including hyphen [-])
0 = DTP mode, 1 = HDBaseT mode
0 = Clear/none (default for telnet)
1 = Verbose mode (default for RS-232 and USB)
2 = Tagged responses for queries
3 = Verbose mode and tagged responses for queries
