Extron DTP T HD2 4K 230/330 • SIS Commands 15
Command and Response Table for SIS Commands
Command ASCII Command
(host to unit)
Response
(unit to host)
Additional Description
Video Mute
Video mute single output
X!*X(B/b VmtX!*X(] X( = 0-2 (default is 0)
Video mute all outputs
X(B/b VmtX(]
Query video mute status
B/b X(•X(]
VmtX(•X(]
Video mute status of outputs 1-2
Verbose Mode 2/3
Embedded Audio Mute
Audio mute single output
X!*X@Z/z AmtX!*X@]
Audio mute of embedded audio only
Audio mute all outputs
X@Z/z AmtX@]
Query audio mute status
Z/z X@•X@]
AmtX@•X@]
Audio mute status of outputs 1-2
Verbose Mode 2/3
TMDS Output Format
Set format for single
output
EX!*X1)VTPO} VtpoX!*X1)] X1) = 0-7 (default is 0)
Set format for all outputs
EX1)VTPO} VtpoX1)]
Query format settings
EVTPO} X1)•X1)]
VtpoX1)•X1)]
Outputs 1-2
Verbose Mode 2/3
Video Color Bit Depth
Set video bit depth for a
single output
EVX!*X#BITD} BitdVX!*X#] X# = 0 (default) or 1
Set video bit depth for all
outputs
EVX#BITD} BitdVX#] X# = 0 (default) or 1
Query video bit depth for
all outputs
EVBITD} X#•X#]
BitdVX#•X#]
Video bit depth of outputs 1-2
Verbose Mode 2/3
NOTES:
X! = Output selection
X@ = Output status
X# = Video color bit depth
X( = Video mute
X1) = TMDS output format
1
through max number of outputs
0
(disabled/off/undetected, default)
, 1
(enabled/on/detected)
0 = auto (based on EDID of sink), 1 = force 8-bit
0 = disabled, 1 = video (TMDS), 2 = video and sync
0 = Auto (default)
1 = DVI RGB 444
2 = HDMI RGB “Full”
3 = HDMI RGB “Limited”
4 = HDMI YUV 444 “Full”
5 = HDMI YUV 444 “Limited”
6 = HDMI YUV 422 “Full”
7 = HDMI YUV 422 “Limited”
