Mounting
Desktop Placement
Attach the four provided rubber feet to the bottom of the DA412GHD‑SDI and place it in
any convenient location.
Rack Mounting
Rack Mounting Procedure
The unit can be mounted on any of the optional Extron rack systems available on the
Extron website. To mount the unit on a rack shelf, read the UL Guidelines, below, and
follow the instructions provided with the shelf kit.
UL Guidelines for Rack Mounting
The following Underwriters Laboratories (UL) guidelines are relevant to the safe installation of
the DA4 12GHD‑SDI in a rack:
CAUTION:
• Elevated operating ambient temperature — If the unit is installed in a
closed or multi‑unit rack assembly, the operating ambient temperature of the
rack environment may be greater than room ambient temperature. Therefore,
install the equipment in an environment compatible with the maximum ambient
temperature (Tma: +122°F, +50°C) specified by Extron.
• Reduced air flow — Install the equipment in the rack so that the equipment
gets adequate air flow for safe operation.
• Mechanical loading — Mount the equipment in the rack so that uneven
mechanical loading does not create a hazardous condition.
• Circuit overloading — Connect the equipment to the supply circuit and
consider the effect that circuit overloading might have on overcurrent protection
and supply wiring. Consider the equipment nameplate ratings when addressing
this concern.
• Reliable earthing (grounding) — Maintain reliable grounding of rack‑mounted
equipment. Pay particular attention to supply connections other than direct
connections to the branch circuit (such as the use of power strips).
DA4 12G HD-SDI • Mounting 21
