Device Menu
The Device menu (see imageon the right) allows the user to:
1
Disconnect the device from PCS
2
View the hardware Settings
3
Reset Device to factory default
4
Update Firmware
5
View information About this Module
ATTENTION:
• Upgrading with incorrect firmware can cause the device to stop responding.
• Effectuer une mise à jour incorrecte de firmware peut interrompre les
communications avec le appareil.
NOTE: Firmware for the DA4 12G HD‑SDI, part number 60‑1674‑01, is 49‑475‑50.
Firmware for the DA4 12G HD‑SDI, part number 60‑1674‑02, is 49‑733‑50. To get
the DA4 part number, see Query unit part number on page10.
Extron PCS Help File
For assistance, ExtronPCSHelp contains complete
information about using the program to configure the
DA412GHD‑SDI.
To access ExtronPCSHelp, click the button in the top right
corner of the PCS program screen (see the image on the
right,
1
) and click on ExtronPCSHelp(
2
).
11
2
2
Updating Firmware Using Firmware Loader
The DA412GHD‑SDI firmware can be upgraded using Extron Firmware Loader.
To download Extron Firmware Loader to your PC, follow these instructions:
1. On the Extron website, mouse over the Download tab (see figure11,
1
).
Figure 11. Locating Firmware Loader Software
2. Click on Software link (
2
) on the drop‑down menu.
11
DA4 12G HD-SDI • SIS Commands 14
