13
For the name of your local stocking distributor, visit www.extech.com
DM220 CAT IV Pocket Multimeter + NCV
Autoranging DMM with 4000 count LCD display, NCV and built-in Flashlight
• Non-Contact Voltage detection identifies live circuits
• Rugged double molded housing; CAT IV-600 V, CAT III-1000 V safety rating
SPECIFICATIONS
RANGE MAX RESOLUTION BASIC ACCURACY (%RDG)
DC/AC Voltage 600 V 0.1 mV DC/1 mV AC ±0.8% DC/±1.5% AC
DC/AC Current 200 mA 0.1 µA ±2.0% DC/±2.5% AC
NC Voltage 100 to 600 VAC
Resistance 40 MΩ 0.1 Ω ±0.8%
Frequency 10 kHz 0.001 Hz ±2.0%
Capacitance 200 µF 0.001 nF ±5.0%
Duty Cycle 0.5 to 99% 0.5% ±(2.0% reading + 5 digits)
Diode/Continuity Yes/Audible
Dimensions/Weight 4.72x2.2x1.6" (120x55x540 mm)/5.12 oz (145 g)
ORDERING
DM220 CAT IV Pocket Multimeter + NCV
MN35/MN36 Digital Mini Multimeters
Autoranging or Manual ranging multimeters with Temperature function
• Large easy to read digital display
MN35 (Manual Ranging/ 8 Functions)
• 1.5 V and 9 V Battery test
MN36 (Autoranging/ 10 Functions)
• AC Current, Capacitance and Frequency measurements
SPECIFICATIONS MN35 BASIC ACCURACY MN36 BASIC ACCURACY
DC Voltage 600 V (0.1 mV) ±0.5% 600 V (0.1 mV) ±0.5%
AC Voltage 600 V (0.1 V) ±1.2% 600 V (0.1 V) ±1.2%
DC Current 10 A (0.1 mA) ±1.5% 10 A (0.1 µA) ±1.2%
AC Current — — 10 A (0.1 µA) ±1.5%
Resistance 20 MΩ (0.1 µΩ) ±0.8% 40 MΩ (0.1 µΩ) ±1.2%
Capacitance — — 100 µF (0.001 nF) ±3.0%
Frequency — — 5 MHz (0.01 Hz) ±1.0%
Temperature -4 to 1400°F (1°)
-20 to 750°C
±(1%+4°) -4 to 1400°F (1°)
-20 to 750°C
±(1%+4°)
Battery Test 9 V and 1.5 V —
Dimensions/Wt 5.43x2.83x1.5" (138x72x38 mm)/5.4 oz (153 g)
ORDERING
MN35 Manual Ranging Mini Digital Multimeter
MN36 Autoranging Mini Digital Multimeter
381676A Pen DMM with Non-Contact Voltage Detector
Autoranging multimeter with non-contact voltage detection
• Autoranging with Data Hold, Range Hold, and Maximum Hold features
• CAT III-600 V; Auto power off, overload and low battery indication
• 2-year warranty
SPECIFICATIONS RANGE MAX RESOLUTION BASIC ACCURACY
Non-contact Voltage >110 V AC
AC/DC Voltage 200 mV, 2, 20, 200, 600 V 0.1 mV AC: ±0.8%; DC: 0.7%
AC/DC Current 20 mA, 200 mA 0.01 µA AC: ±2%; DC: 0.1.5%
Resistance (Ω) 200, 2 k, 20 k, 200 k, 2 M, 20 MΩ 0.1Ω ±0.8%
Logic Test 0 to 1.5 V (Green LED), 1.5 to 3.5 V (LED off), 3.5 to 5 V (Red LED)
Diode/Continuity Yes/Audible
Dimensions/Weight 8.2x1.5x1.1" (208x38x29 mm)/4.6 oz (129 g)
ORDERING
381676A Pen DMM with Non-Contact Voltage Detector
Includes holster with stand,
Type K bead wire probe, battery,
and test leads; 2-year warranty
Compact Multimeters and Pen Multimeter
Includes test leads and
two AAA batteries; 2-year
warranty
Includes test leads, two
alligator clips, two 1.5 V
AAA batteries, and soft
case
