18
English EX-45032IS
If you are ready with the jumper settings, please proceed with the following installation instructions.
Because there are large differences between PC’s, we can give you only a general installation guide
for the EX-45032IS. Please refer to your computer’s reference manual whenever in doubt.
1. Turn off the power to your computer and any other connected peripherals.
2. Remove the mounting screws located at the rear and/or sides panels of your Computer and
gently slide the cover off.
3. Locate an available expansion slot and remove its covers from the rear panel of your
computer. Make sure it is the right expansion slot for the card (see card description)
4. Align the card with the PCI-Express slot and then gently but firmly, insert the card. Make sure
the card is seated and oriented correctly. Never insert the card by force!
5. Then connect the card with a screw to the rear panel of the computer case.
6. Gently replace your computer’s cover and the mounting screws.
© Copyright 2020 by EXSYS Vertriebs GmbH. All Rights Reserved
5. Hardware Installation
6. Driver Installation
Windows
After completing the hardware installation, the operating system will automatically the card and
install this! If the driver should not be installed automatically, you must manually install two drivers.
One ist the USB host driver and the other is the USB to serial driver. for this insert the driver CD
into you CD-ROM drive (eg drive D:) and then start the „SETUP“ which is located in folder
„uPD720201_202“ (see picture): Follow the hardware assistant and finish the installation.
Important! Restart your PC in any case after installing the drivers.
