EN
Seite | 21
Service workshop or by a person
with the necessary qualifications in
the event of damage.
9 Unpacking, assembling
and setting up the
appliance
✓ Take care when opening the
appliance packaging.
✓ Remove the fan from the
packaging.
✓ Check whether the delivery is
complete (see Fig. 2).
✓ Check the fan and all the
individual parts for damage.
If this is the case, do not put the fan
into operation. Please contact After
Sales Service
www.ggv-service.de
APPLIANCE DAMAGE!
If you open the packaging carelessly
with a sharp knife or other pointed
object, the fan can be easily
damaged.
Assembling the appliance
RISK OF ELECTRIC
SHOCK!
The fan must not be connected to
the mains power supply during
installation.
Scope of supply for installation
4 rubber feet
4 screws (for attaching the lower
pedestal tube)
Installation steps (Fig.2)
1. Assemble the parts of the feet
(17) to form a cross.
2. Push the 4 rubber feet onto
the ends of the cross stand.
3. Screw pedestal tube (15) to
cross stand (17) using the
screws supplied.
4. Pull out telescopic rod (13)
and loosen pipe connector
(14).
5. Push protective cover (18)
over the telescopic rod and
the lower tube onto the cross
stand.
6. Fit the pipe connector again
and screw tight.
7. Attach component to control
panel (11) to the upper tube
and secure or fix with locking
screw (12).
8. Loosen and remove mounting
screw (3) and mounting nut
(3) from motor shaft (7).
9. Attach hinge cap (1) with
three screws to the front
protective grille. Ensure that
the logo is horizontal in
relation to the small mounting
screw on the protective grille.
10. Position rear protective grille
(6) firmly on the motor
housing. Ensure that the
device for fitting the screw is
horizontal in relation to the
motor shaft.
11. Fit mounting nut (5) and
tighten in clockwise direction.
12. Push fan vanes (4) onto the
motor shaft.
13. Fit mounting screw (3) on the
motor shaft and tighten in
anti-clockwise direction.
14. Attach front protective grille
(2) to the rear protective
grille. Secure with the screw
and the preassembled clips.
