Getting to know your appliance
Scope of supply
1x Appliance
2x Flue panels 400 mm with wall bracket and
flue panel brackets
1x Air outlet cover
1x Accessory material
1x Exhaust air hose 153mm Ø, 1.5 m length
1x Instruction manual
Designation
1) Flue
2) Control panel
3) Light
4) Housing
Not included in the scope of supply:
• Activated charcoal filter for recirculating air
operation
Available as options from After Sales Service
Control panel
BUTTON SYMBOL
ZIFFER
FUNCTION
9 ON/OFF
Button for switching the appliance on and off. When
the appliance is switched on, the fan starts at level
1.
5 Timer
Button for setting a "run-on time" for the fan. When
the button is pressed, the fan continues to run for 5
minutes and then switches off. The timer button is
inactive when the appliance is in standby mode.
6 Light
Button for switching the light ON and OFF.
8 Power level
Button for switching off the fan
7 Power regulator
Controller for setting the fan speed
APPLIANCE
DIMENSIONS
MM
Height
736-1116
Width
600
Depth
468
Exhaust air
fitting Ø
150
