Setting up and connecting
Page 25 of 36
ATTENTION
APPLIANCE DAMAGE!
Leave the appliance to stand for 12 hours after transport to allow the refrigerant to
collect in the compressor. Failure to observe this may damage the compressor and cause
the appliance to fail. This would void all warranty claims.
CLIMATE CLASS
TEMPERATURE RANGE
(SN) Extended temperature range
+10 °C to +32 °C
(N) Temperature range
+16 °C to +32 °C
(ST) Subtropical temperature range
+16 °C to +38 °C
(T) Tropical temperature range
+16 °C to +43 °C
Minimum clearances for ventilation
Air circulation at the rear, side and top of the appliance influences energy consumption
and refrigerating (depending on model). It is essential that the minimum clearances for
ventilation of the appliance are observed as shown in the following drawing. If the
minimum clearances are not observed, the accumulated air cannot escape and the
compressor is in continuous operation, which shortens the life of the appliance.
Appliance dimensions in mm and degrees
a
b
c
e
f
546
479
854
50
50
Ø Failure to observe the minimum distances increases power
consumption.
Ø If the accumulated heat cannot dissipate around the appliance, the
function of the appliance will be impaired.
Ø To achieve the specified energy class, comply with the above
mentioned clearances.
Ø Do not install refrigerator/freezer combinations with only one
temperature regulator in refrigerated rooms below 16 °C.
10.2 Levelling
If the surface is slightly uneven, level the appliance with the
front feet.
