8
Water line Adapter:
The machine comes equipped with a braided stainless steel water line. Included is a brass
adapter that has a 3/8” male flair fitting. You will nee
d to use a 3/8” female flair fitting to
hook up to it.
Brewtus IV
-
P
with Plumbing K
it
and Reservoir
The Br
ewtus IV
-
P
can be used
either with a water line hookup or the included reservoir.
There is
a
lever on the bottom of the machine that you ca
n use t
o alternate between the
plumbed line and water reservoir
.
The machine will be shipped from Whole Latte Love
ready to use with the reservoir. If you want to use it with the water line hook up
, you will
have to move the control lever
and
the wires on the Mic
ro Switch that senses the weight
of the reservoir
as shown below.
Turn this lever forward for water line
connection and
back for reservoir
connection. (T
he image below shows
it set up for a water line).
The flexible drain
line that was
supplied with the
machine sli
des over
this fitting.
To access the micro
switch under
the
reservoir remove the housing (5
screws) and the reservoir holding
plate
(t
w
o Philips head screws and
two 3
mm A
llen screws)
UNPLUG the
machine when
performing any of
these functions
.
Two 3mm
Allen screws
Reservoir
holding plate
