16
INSTALLATION
1. Remove the power supply from its
packaging.
2. Use the included screws to install the
power supply into your computer case.
COMMENT: We recommend installing the
power supply with the fan pointing
downwards. However, if the power supply
will be placed on the bottom of your
computer case and there are no ventilation
holes, it may be best to install the power
supply with the fan facing upwards to
ensure greater efficiency and reliability.
3. Connect the 24-pin ATX cable to the
motherboard. COMMENT: This power
supply allows you to disconnect the four
pins on the far right to make this connector
a 20-pin connector. Under no
circumstances should you plug another 4-
pin connector into the 4-pin ATX12V or
"P4" connector on the motherboard.
Serious damage can occur.
4. Connect the 8pin EPS12V cables to the
motherboard. One of the EPS12V
connectors can be split to create a 4pin
ATX12V connector if your board does not
have an EPS12V connector.
