INSTALLATION PRECAUTIONS
• Feed water supply pressure must not exceed 125 psi (non-shock).
When pressure exceeds 85 psi, a pressure reducing valve is
recommended.
• If water hammer is evident, install a water hammer arrestor
before the Pentair® Everpure® system.
• Do not use liquid pipe compounds for tting connections.
Use two (2) or three (3) wraps of PTFE thread sealant tape.
• Do not over-tighten tting connections. Always back-up valves
and ttings with a wrench to avoid excessive stress on system
components.
INSTALLATION PROCEDURE
IMPORTANT: Conrm with the manager, and or owner/operator
that equipment to be fed by the ltration system is turned off or
not in use. The water supply to equipment will be shut off during
installation.
NOTE: For installations in Australia and New Zealand product must
be installed with a backow prevention device in accordance with
AS/NZS 3500 and AS/NZS 2845.1.
1. Locate the feed water supply shut-off valve and turn off.
NOTE: If not available, we recommend the installation of a
full-ow ball valve on the supply line to be connected to the
Pentair Everpure system. This will allow the system to be
serviced without shutting off the main water supply. (It will not
be necessary to use this valve when replacing lters.)
2. Use the predrilled mounting holes in the manifold bracket as a
guide to mark and drill anchor holes. Mount the system securely
using fasteners suitable to support the operating weight of the
system.
3. Connect the feed water supply line from the full-ow ball valve
to the inlet connection of the Everpure system.
Use a minimum 3/8-inch water line for the “single”
models. Use a minimum 1/2-inch water line for
“twin”, “triple” and “quad” models.
4. Connect tubing (supplied) to ush valve located at
the bottom of the system outlet tting and route
to drain.
NOTE: Some municipal plumbing codes and good sanitary
practices require an air gap at the drain termination point.
5. If the model includes a pre-lter, install the pre-lter. Check
to be sure the O-ring on the pre-lter housing is suciently
lubricated. If needed, use a good grade of silicone lubricant.
Insert the pre-lter into the sump and position the cartridge on
guide seat in the bottom of the sump. Then thread the sump into
the head by hand. Hand-tighten to snug the sump onto the head.
6. Install the primary lter cartridge(s) into the lter head(s)
following the directions below or as shown in the Cartridge
Change Instructions (p.6).
A. Hold lter head rmly. Align cartridge lug with label – push up
and insert the new cartridge rmly into the head.
B. Turn cartridge to right (1/4 turn) until rotation stops.
7. Select the appropriate size supply line for the equipment being
served and connect it to the outlet port of the system.
8. Connect the outlet supply line to equipment served as required.
9. With the system inlet shut-off valve in the closed/off position,
slowly open the feed water supply full-ow ball valve. Check for
leaks from the plumbing leading to the system inlet connection.
10. Ensure the ush valve line is securely attached at the drain, or
hold the tubing over a bucket or drain.
11. Slowly open the system inlet valve and allow water to ow
through the ush valve for ve (5) minutes to purge air and ush
the system media.
12. After ushing, close the ush valve and check for leaks.
13. If no leaks, the installation is complete.
14. Inform the manager and or owner/operator that the equipment
serviced can now be turned on and checked for normal
operation.
Leave this installation, operation, and maintenance manual
with the establishment for future reference.
WARNING: FOR CORRECT OPERATION OF THIS APPLIANCE IT IS
ESSENTIAL TO OBSERVE THE MANUFACTURER’S INSTRUCTIONS.
Air Gap
PENTAIR® EVERPURE® FC SERIES WATER FILTRATION SYSTEMS INSTALLATION, OPERATION & MAINTENANCE GUIDE • 3
