PENTAIR EZ-RO INSTALLATION AND OPERATION GUIDE FOODSERVICE.PENTAIR.COM | 11
ATTACH SOLENOID CABLE AND POWER CORDS
1. Connect M12 connector cable from ATM tank to RO
processor. This cable controls power to RO solenoid
valve. Cable is 9 feet long. (An M12, 2 pin connector can
be used for extensions if required, not included.)
2. Connect power supply to power supply cord on the
ATM Tank.
3. Securely mount the power supply block in a dry
location. Wrap supply block with two zip ties (included)
and screw zip ties to wall. Ensure cord length can
reach wall outlet.
IMPORTANT: Do not plug in to power yet.
2
3
1
OVERALL VIEW OF COMPLETED INSTALLATION
INSTALL
