PENTAIR EZ-RO INSTALLATION AND OPERATION GUIDE FOODSERVICE.PENTAIR.COM | 13
SYSTEM STARTUP AND FLUSHING PROCESS (CONTINUED)
11. Connect tank power supply to wall outlet.
12. Check system status light: yellow indicates tank is
at low level.
• RO Processor will power solenoid and water will
begin to ow from drain and through the TO TANK
line that is secure in the sink.
• Check for any leaks. Shut off water and repair
leaks if required. Turn incoming feed water back
on when corrected.
NOTE: The pump might turn on quickly and then it
should turn off. If pump continues to run, disconnect
power, check ATM tank to ensure the low level sensor
is connected and no water is in tank. Reconnect power.
See Troubleshooting.
5 MINUTE FLUSHING OF PREFILTER AND MINERAL
ADDITION CARTRIDGE.
13. Flush prelter and mineral addition cartridge for
ve minutes or until water runs clear.
• With power on, and solenoid valve open, ushing
will proceed through reject outlet and through
TO TANK port at this time.
REMOVE SYSTEM PRESSURE
14. Turn off incoming feed water from source.
15. Pressure should drop to 0 psi.
NOTE: Leave power on.
11
12
13
EZ-375 RO Module - Reject Line Flow Restrictor Guide ATM Systems
RO Permeate Production Rate
High Medium Low
FEED WATER
TDS / PPM
psi greater than 70
or LpM greater than 0.75
psi between 50 & 70
or LpM between 0.5 & 0.75
Low Pressure /
Low Temperature
LpM Less than 0.50
Soft Water & >300 WHITE 1.052 LpM BLUE 0.735 LpM GREEN 0.525 LpM
300 to 800 WHITE 1.052 LpM WHITE 1.052 LpM BLUE 0.735 LpM
800 to 1200 GRAY 1.577 LpM* GRAY 1.577 LpM* WHITE 1.052 LpM
EZ-650 RO Module - Reject Line Flow Restrictor Guide ATM Systems
RO Permeate Production Rate
High Medium Low
FEED WATER
TDS / PPM
psi greater than 70
or LpM greater than 1.4
psi between 50 & 70
or LpM between 0.9 & 1.4
Low Pressure /
Low Temperature
LpM Less than 0.90
Soft Water &<300 GRAY 1.577 LpM* WHITE 1.052 LpM BLUE 0.735 LpM
300 to 800 GRAY 1.577 LpM* GRAY 1.577 LpM* WHITE 1.052 LpM
800 to 1200 ORANGE 2.000 LpM ORANGE 2.000 LpM GRAY 1.577 LpM*
*GRAY 1.577 LpM ow restrictor comes pre-installed in RO processor.
Production rate can be between High/Medium/Low caused by water temperature, incoming pressure (psi), and TDS of water.
NSF testing completed at inuent water conditions of 750 ppm TDS and at 50 psi water, using reject ow restrictor as indicated.
15
REJECT FLOW RESTRICTOR CHART
FLUSH FLOW RESTRICTOR
14
