EFN Series Fisheye IP Camera
11
3.3.2 Indoor Type – Wall Mount
You can mount the camera to the wall using the supplied Base Plate or the Tilting Wall Mount Bracket.
With the Tilting Wall Mount Bracket
With the Base Plate
1. Stick the Mounting Template to the wall. Drill the three red cross marks on the inner circle. If you
want to use the supplied Tilting Wall Mount Bracket, drill the three black cross marks on the outer
circle. Drill the square below only if you wish to run the cables through the wall. Note that the square
below also indicates the cable position. Point the square below to the direction for running the
cables.
Drill a hole only if you want to
run the cables through the wall.
Toward the ground
For the Tilting Wall Mount Bracket
