2.1.7.1. Configuring your Aached Pedal
Use the cursor buons to highlight the “Pedal 1 Mode” or “Pedal 2 Mode” mode.
Press the Enter key, then use the cursor keys or wheel to navigate among the pop-up menu of
opons. Available choices include:
Expression Pedal
2 Expression Pedals
1 Expression Pedal + 1 Aux Switch
1 Aux switch + 1 Expression Pedal
2 buon Aux Switch
3 buon Aux Switch
Aer you have selected the mode appropriate for your connected switch/pedal, press the Enter key to
save your selecon.
2.1.7.2. Calibrang Your Aached Pedals and Switches
Once you have selected your desired type of pedal/switch, the H9000 will populate the rest of the
display with relevant calibraon tools.
Use the cursor buon and the Enter key to navigate to and engage the “Calibrate” field.
If you have aached an on/off type pedal, physically press each switch and make sure that you see
the appropriate “SW” circle illuminate. There are separate SW circles for 1, 2, or 3 buon pedals. 3
SW circles are shown for 1, 2, or 3 buon pedals because even a single aux switch may not be
sent out as SW1 but may instead be sent out as SW2.
If you have aached a connuous foot pedal, navigate to the “Calibrate Pedal” field, then sweep
the pedal back and forth with your foot. You should see the Calibrate Pedal field display a range
between 0-100% on the calibraon meter.
When you’ve finished calibrang, disengage the “Calibrate” buon using the Enter key.
Even though there are only two pedal/switch connectors on the H9000, you can connect up to four
pedals. This is made possible by connecng two pedals to each connector using a “Y” cable:
hps://
ede.io/TRS
This capability is possible because:
In the external control secon of the Parameters mode, there are 4 expression pedals listed.
In set-up mode, there are opons to configure a single connector to be connected to two separate
expression pedals.
•
•
•
•
•
•
•
•
•
•
•
•
•
•
24
2. SETUP
