SC3070
LED Mode
12
OPERATION
The Mid Filter is a bell lter with 1kHz center frequency. It allows you to
boost or cut the mid range up to +/-3dB in 0.5dB steps.
This frequency range is very important for the balance between lower
mid and higher mid frequencies. Use the Mid lter to adjust the balance
between fundamental and harmonic frequencies in the music material.
Depending on the acoustics of your room, some of the sound energy
produced by the monitors may be reected by surfaces like walls, oor
and/or ceiling in the room, thus altering the perceived sound.
3.12. Desk Filter
0
+5
+3
-5
-3
100 1k 10k
dB
Hz
The Desk Filter has two functions. When turned down it acts as a narrow-
band EQ set to 160Hz.
The reections of mixers and similar surfaces usually result in the boosting
of low mids. With the Desk Filter you can lessen this eect by turning down
the lter gain.
When turned up, the Desk Filter also works as an EQ but this time set to
80Hz. This allows you to give more punch to the lower frequencies.
! The following applies to the Low, High and Desk lters:
• Every step represents a 0.5dB increment.
• Maximal boost is +3dB and maximal attenuation is –5dB.
• Refer to the chapter on POSITIONING to set the lters of your EVE Audio
monitors eectively.
3.13. LED Mode
The LED mode determines in which of the four available fashions the LED
ring displays the volume level. The LEDs represent given levels, which are
displayed and adjusted according to four steps. Intermediate steps are
indicated by the brightness between two adjacent LEDs.
