OPERATION
3.11. LED Mode
The LED mode determines in which of the four available fashions the LED
ring displays the volume level. The LEDs represent given levels, which are
displayed and adjusted according to four steps. Intermediate steps are
indicated by the brightness between two adjacent LEDs.
• Bright Ring
All LEDs up to the selected volume level light up brightly. The louder the
signal, the longer the brightly lit-up ring.
• Bright Point
Only the LEDs corresponding to the selected volume level light up brightly.
The louder the signal, the further up the brightly lit-up point moves.
• Dimly Lit Ring
All LEDs up to the selected volume level light up dimly. The louder the
signal, the longer the dimly lit-up ring. In this mode, the LEDs light up
brightly momentarily while you adjust the volume level.
• Dimly Lit Point
Only the LEDs corresponding to the selected volume level light up dimly.
The louder the signal, the further up the dimly lit-up point moves.
! Intermediate steps are indicated by the lighting of two adjacent LEDs. The
level ranges from -60dB to +10dB, taking “0dB“ as reference point.
3.12. Saving Your Settings
All settings on the front and rear panels are automatically saved. The
loudspeakers can be disconnected anytime without the settings being
lost.
3.13. Power Switch
The power switch on the rear panel disconnects the loudspeaker
completely from the power grid. When powered o all settings are saved
and the power consumption is reduced to 0watt.
After powering on again, the loudspeaker will return to the state it was
in before being turned o (Standby mode, Mute mode or a given volume
level). Even if powered o via a multiple outlet power strip, the monitor will
return to the state it was in before being turned o.
! In order to prevent switching noise with your monitoring system, keep in
mind the following rules:
Power all audio sources on rst and your loudspeakers last.
