22
Carbon Installation and Changeover (Recirculating Mode Only)
Note: A set of the CF110 Carbon Filters is required for the below steps.
• If the recirculating installation is utilised then a carbon filter must
be fitted to aid in the removal of grease, smoke and cooking
odours from the air before it is recirculated into the room.
How to install/replace carbon filters
1
Push the handle of the bae filters towards the rear of the rangehood until they’re
released from the housing and then remove them and set aside, figure 1.
2
Remove the old carbon filters (if fitted) by twisting them anti-clockwise
until they unlatch from the sides of the motor, figure 2.
3
Position the new carbon filter onto the side of the motor, ensuring the
central groove point is lined up with protruding tongue on the motor housing.
4
Twist the carbon filter clockwise until it clicks into place, figure 2.
5
Repeat for the other filter.
6
Re-insert the bae filters (set aside in step 1) into
the housing ensuring they click into place, figure 1.
Note: it is recommend to replace the carbon filters every 3-4 months
or sooner, depending on how frequently the rangehood is used,
otherwise the performance of the rangehood can be impeded.
INSTALLATION
1 2
