20
9
Attach the loose end of the ducting to the inlet of the T-shape deflector
using a cable tie. Now fix the deflector to the flue extension with 2 screws on
either side. Ensure ducting is pulled tight and the excess is removed, figure 9.
10
Secure both the stability bracket and the rangehood to the wall via
the designated fixing points, figure 10. Ensure suitable anchors and
screws are used to secure both the stability bracket and the rangehood.
INSTALLATION
109
T-shape deflector
