00101069, Version 1.1

11/14

The device must always be installed via all fixation holes. Do only use appropriate screws and make sure

that the screws are properly connected with the ground.

The durability of the installation depends very much on the material used at the installation area (building

material) such as wood, concrete, gas concrete, brick etc. This is why the fixing material must be chosen to

suit the wall material. Always ask a specialist for the correct plug/screw combination indicating the maximum

load and the building material.

Remove the mounting clips (2 versions) and screws included in delivery from the packaging and use

whichever clips are most suitable for the desired mounting area.

Procedure:

Step 1: Hold the clips onto the location where the device is to be installed.

Step 2: Mark the boreholes with a pen or a suitable tool.

Step 3: Drill the holes.

Step 4: Screw the suitable clips into the installation surface.

Step 5: Press the luminary carefully into the mounting clips until it clicks and the device is firmly fixed.

DANGERTOLIFE!

Beforetakingintooperationforthefirsttime,theinstallationhastobeapprovedbyanexpert!

Connection with the mains

Connect the device to the mains with the power plug. The occupation of the connection cables is as follows:

Cable

International

Brown Live L

Blue Neutral N

Yellow/Green

Earth

Attention! The earth has to be connected!

If the device will be directly connected with the local power supply network, a disconnection switch with a

minimum opening of 3 mm at every pole has to be included in the permanent electrical installation.

The device must only be connected with an electric installation carried out in compliance with the IEC

standards. The electric installation must be equipped with a Residual Current Device (RCD) with a maximum

fault current of 30 mA.

OPERATION

Install the device on a plane surface.

After you connected the device to the mains, the UV-bar lamp needs 3-4 minutes warm-up time until it

reaches full lighting output.
