OPERATION

After connecting the device to the mains it is ready for operation. The display indicates the last operating

mode. The operating modes can be selected by means of the display and the control buttons. All settings

remain stored even if the device is disconnected from the mains. The device can be operated in stand-alone

mode via the control board and the EUROLITE IR-7 remote control or in DMX-controlled mode via any

commercial DMX controller as well as wireless via QuickDMX with the optional available EUROLITE

QuickDMX USB Wireless Transmitter/Receiver.

Menu structure

Mode

Display

Function

DMX mode

Addr

24CH d001-512 24-channel mode and start address

16CH d001-512 16-channel mode and start address

9CH d001-512 9-channel mode and start address

8CH

d001-512

8-channel mode and start address

6CH

d001-512

6-channel mode and start address

5CH

d001-512

5-channel mode and start address

4CH

d001-512

4-channel mode and start address

3CH

d001-512

3-channel mode and start address

Preset colors

Stat S 01-19 Constant lighting in one of 19 colors

Automatic mode

Auto Au 1-9 Auto programs

Sound control

Soun So 1-9 Sound programs

Running speed in

automatic mode

SPEE SP 1-9

Program running speed

slow > fast

Microphone sensitivity

for sound control

SEnS SE 1-9

Microphone sensitivity

low > high

Individual color mix

Colo

r000-255 Red 0-100%

g000-255 Green 0-100%

b000-255 Blue 0-100%

U000-255 Warm white 0-100%

Dimmer

diMM dI 1-dI 9

Total brightness

dark > bright

Sound control silent

scene

SILE

on LEDs off if there is no music signal

oFF

LEDs remain on if there is no music signal

Behavior in case of

missing DMX signal

Lost

blaC LEDs switched off

Hold

Most recent DMX value is held

FuLL All LEDs 100% on

Stat Pre-selected static color 01-19

Auto Pre-selected auto program 01-09

Slave mode

SLAV SLAU Slave mode

IR remote control

InFr

IR remote control on

oFF IR remote control off

Version

Vxxx Vxxx Current software version
