00158055, Version 1.1

42/44

TECHNICAL SPECIFICATIONS

Power supply: 100-240 V AC, 50/60 Hz

Power consumption: 115 W

IP classification: IP20

Protection class: Protection class I

Power connection: Mains input via P-Con (blue), mounting version

Cable construction: 3 x 1.0 mm² H05VV-F

Cable length: 1.45 m

Power output: 1 x P-Con (gray), mounting version

Fuse: 5 x 20 mm, T 2 A fuse replaceable

Lamp type: LED lamp

LED: 25 x 12 W SMD 5050 4in1 QCL RGB/WW

DMX channels: 4; 10; 15; 100; 102

DMX input: 3-pin XLR (M) mounting version

DMX output: 3-pin XLR (F) mounting version

Network connection: 2x RJ-45 (F) mounting version

Cooling: Temperature-controlled fan

Control:

Stand-alone; DMX; QuickDMX via USB (optional); RDM; Art-Net:

W-DMX by wireless solution via USB (optional); CRMX by

LumenRadio via USB (optional); sound to light; master/slave

function

Projection: Flicker-free

DMX fail mode: Hold; blackout

Beam angle (1/2 peak): 45°

Beam angle (1/10 peak): 82°

Housing color: Black

Attachment system: Mounting bracket

Display type: Multicolor LCD display

USB port: Typ A

Diameter mounting holes: 3 x Ø10mm

Material: Metal

Dimensions:

Width: 45.0 cm

Depth: 10.6 cm

Height: 45.0 cm

Weight: 7.7 kg

All information is subject to change without prior notice. © 27.11.2024

106mm

450 mm
