00159041, Version 1.0

42/44

TECHNICAL SPECIFICATIONS

Power supply: 100-240 V AC, 50/60 Hz

Power consumption: 60 W

IP classification: IP20

Protection class: Protection class I

Power connection:

Mains input via P-Con (blue), mounting version

Power supply cord with safety plug

Cable length: 1.4 m detachable

Power output: P-Con (gray), mounting version

Fuse: 5 x 20 mm, T 2 A fuse replaceable

Lamp type: LED lamp

LED type: 10 x 12 W SMD 5050 4in1 QCL RGB/WW (homogenous color mix)

DMX channels: 4; 10; 15; 40; 42

DMX input: 3-pin XLR (M) mounting version

DMX output: 3-pin XLR (F) mounting version

Network connection: Protocol: ArtNet 3 via 2x RJ-45 E-Con (F) mounting version

Cooling: Passive convection cooling

Control:

Stand-alone; DMX; QuickDMX via USB (optional); RDM; Art-Net: W-DMX

by wireless solution via USB (optional); CRMX by LumenRadio via USB

(optional); sound to light; master/slave function

Projection: Flicker-free

PWM frequency: 2900 Hz

DMX fail mode: Hold; blackout

Beam angle (1/2 peak): 45°

Beam angle (1/10 peak): 82°

Housing color: Black

Attachment system:

Panning and tilting mounting bracket for ceiling or wall installation in most

varying angles

Bracket for floor use

Display type: Multicolor LCD display

USB port: Typ A

Diameter mounting holes: 3 x Ø10mm

Material: Metal

Dimensions:

Width: 45.0 cm

Depth: 13.5 cm

Height: 20.3 cm

Weight: 5.50 kg

All information is subject to change without prior notice. © 27.11.2024

203 mm

180 mm

450 mm
