00159459, Version 1.0

42/44

TECHNICAL SPECIFICATIONS

Power supply: 100-240 V AC, 50/60 Hz

Power consumption: 60 W

IP classification: IP20

Protection class: Protection class I

Power connection:

Mains input via P-Con (blue), mounting version

Power supply cord with safety plug

Power output: P-Con (gray), mounting version

Fuse: 5 x 20 mm, T 2 A fuse replaceable

Lamp type: LED lamp

LED type:

10 x 12 W SMD 5050 4in1 QCL RGB/WW

(homogenous color mix)

DMX channels: 4; 10; 15; 40; 42

DMX input: 3-pin XLR (M) mounting version

DMX output: 3-pin XLR (F) mounting version

Network connection: Protocol: ArtNet 3 via 2x RJ-45 E-Con (F) mounting version

Cooling: Passive convection cooling

Control:

Control via RDM; ArtNet; stand-alone; DMX; QuickDMX via

USB (optional); W-DMX by wireless solution via USB (optional);

CRMX by LumenRadio via USB (optional); master/slave

function; sound to light

Projection: Flicker-free

PWM frequency: 2900 Hz

DMX fail mode: Blackout; hold

Beam angle (1/2 peak): 45°

Beam angle (1/10 peak): 82°

Housing color: Black

Attachment system: Bracket for floor use

Display type: Multicolor LCD display

USB port: Typ A

Diameter mounting holes: 3 x Ø10mm

Material: Metal

Dimensions:

Length: 90 cm

Depth: 13.5 cm

Height: 14.9 cm

Weight: 6.00 kg

All information is subject to change without prior notice. © 27.11.2024

900 mm

149 mm
