00107911.DOC, Version 1.0
23/24
Should you have further questions, please contact your dealer.
TECHNICAL SPECIFICATIONS
Power supply: 100-240 V AC, 50/60 Hz ~
Power consumption: 250 W
Number of DMX channels: 3
DMX-512 connection: 3-pin XLR
Maximum ambient temperature T
a
: 45° C
Maximum housing temperature T
C
(steady state): 65° C
Minimum distance from flammable surfaces: 0.5 m
Minimum distance to lighted object: 0.3 m
LED type: 250 W COB, warm white
Number of LEDs: 1
Color temperature: 3000 K
Beam angle: 14-41°
Dimensions (LxWxH): 645 x 270 x 375 mm
Weight: 12.6 kg
Acce
ssories:
Article No.:
EUROLITE Iris for LED PFE-100/120 No. 40001983
EUROLITE Gobo Holder for LED PFE-100/120 No. 40001984
EUROLITE Filter Frame for LED PFE-100/120 No. 40001985
EUROLITE STV-20 Follow Spot Stand No. 59007120
EUROLITE TPC-10 Coupler, silver No. 59006856
EUROLITE TPC-10 Coupler, black No. 59006858
EUROLITE Safety Bond A 4x1000mm up to 15kg silver No. 58010320
EUROLITE Safety Bond A 4x1000mm up to 15kg black No. 58010344
EUROLITE DMX cable XLR 3pin 3m bk No. 3022785H
PSSO DMX cable XLR 3pin 3m bk Neutrik No. 30227810
SOMMER CABLE DMX cable XLR 3pin 3m bk Hicon No. 30307457
SOMMER CABLE DMX cable XLR 3pin 3m bk Neutrik No. 3030746Z
PSSO PowerCon Connection Cable 3x1.5 1.5m No. 3023503L
ROADINGER Flightcase 2x PFE-100/120 No. 31005096
Please note: All information is subject to change without prior notice. 24.05.2017 ©
