Je bekijkt pagina 17 van 24
00107911.DOC, Version 1.0
17/24
DESCRIPTION OF THE DEVICE
Features:
Professional stage spot light
• Equipped with 1 x 250 W COB LED, warm white
• Ideal for theatres and stages
• Operable in stand-alone mode or via DMX
• DMX512 control possible via any commercial DMX controller (occupies 3 channels)
• Comfortable addressing and setting via control board with LCD display and four operating buttons
• Master/Slave function
• Strobe effect
• Dimmer
• Dimmer speeds (step response) adjustable via DMX
• Focus manually adjustable
• Manually adjustable zoom
• Color filter frame and 4 shutter blades included in delivery
• Locking possibility at the mounting bracket
• Power connection via P-Con jack and included power cable with safety plug
• Switch-mode power supply for operation between 100 and 240 Volts
• Feed-through output allows to power up to 8 devices
• After every 8 LED Profile Spots the fixtures must have a renewed connection with the power mains
Overview
(1) Filter frame
(2) Housing
(3) Attachment eyelet
(4) Profile slider
(5) Mounting bracket
(6) Fixation screws
(7) Profile slider
(8) Lens
(9) Focus slider
(10) Zoom slider
(11) Mounting slot for Iris/Goboholder
(12) MODE button
(13) ENTER button
(14) Display
(15) DOWN button
(16) UP button
(17) Insulated handles
(18) Power supply via P-Con socket
(19) DMX In socket
(20) DMX Out socket
(21) Power output via P-Con socket
(22) Insulated handles
