00139205.DOCX, Version 1.0
27/28
TECHNICAL SPECIFICATIONS
Power supply: 100-240 V AC, 50/60 Hz
Power consumption: 130 W
IP classification: IP20
Protection class: Class I
Power connection:
Mains input P-Con (blue), mounting version
Power supply cord with safety plug (provided)
Power output: P-Con (gray), mounting version
Lamp type: LED lamp
LED: 1 x COB (chip-on-board) 200 W warm white (WW)
Color temperature: 3000K
Equipment: Zoom manual; Focus manual
DMX channels: 3
DMX input: 3-pin XLR (M) mounting version
DMX output: 3-pin XLR (F) mounting version
Cooling: Cooling fan
Control: DMX; stand-alone; Light Captain
Beam angle (1/2 peak): 14 - 41°
Color rendering index (CRI) more than: 95 Ra
Housing color: Black
Display type: LCD
Dimensions:
Length: 61.8 cm
Width: 33.1 cm
Height: 36.2 cm
Weight: 10.7 kg
Accessories
EUROLITE Iris for LED PFE-100/120 No. 40001983
EUROLITE Gobo Holder for LED PFE-100/120 No. 40001984
EUROLITE Filter Frame for LED PFE-100/120 No. 40001985
EUROLITE STV-20 Follow Spot Stand No. 59007120
EUROLITE TPC-10 Coupler, silver No. 59006856
EUROLITE TPC-10 Coupler, black No. 59006858
EUROLITE Safety Bond A 4x1000mm up to 15kg silver No. 58010320
EUROLITE Safety Bond A 4x1000mm up to 15kg black No. 58010344
EUROLITE DMX cable XLR 3pin 3m black No. 3022785H
PSSO DMX cable XLR 3pin 3m black Neutrik No. 30227810
PSSO PowerCon Connection Cable 3x1.5 1.5m No. 3023503L
ROADINGER Flightcase 2x PFE-100/120 No. 31005096
All information is subject to change without prior notice. © 13.05.2022
33.1 cm
61.8 cm
36.2 cm
