DMX operation
Setting the DMX starting address
For operation with a controller with DMX512 protocol, the device is equipped with 3 control channels. To be
able to operate the device with a DMX controller, the DMX starting address must be set. The starting
address depends upon which DMX controller is being used. Please refer to the controller’s documentation.
1 Press the MODE button so many times until DMX512 is indicated in the display. Confirm with the ENTER
button.
2 Use the buttons UP and DOWN to set the address. Confirm with the ENTER button.
3 The display will not flash when DMX signals are being received. If no control signals are available, the
display will flash. The display shuts off after 120 seconds of inactivity. With the touch of a button it lights
up again.
Note: Please make sure that you do not have any overlapping channels in order to control each device
correctly and independently from any other fixture on the DMX chain. If several devices are addressed to the
same address, they will work synchronously.
Functions in DMX mode
Channel 1 – Dimmer
Value:
Function:
001 – 255 0 – 100% Increasing brightness
Channel 2 – Strobe
Value
:
Function
:
000 – 009 No function
010 – 255 0 – 100 % Increasing speed
Channel 3 – Dimmer speed (step response)
Value
:
Fun
c
tion:
000 – 063 Dimmer speed 1
064 – 127 Dimmer speed 2
128 – 191 Dimmer speed 3
192 – 255 Dimmer speed 4
