00129744.DOCX, Version 1.1

46/48

TECHNICAL SPECIFICATIONS

Power supply: 100-240 V AC, 50/60 Hz

Power consumption: 90 W

IP classification: IP20

Protection class: Class I

Power connection:

Mains input P-Con (blue), mounting version

Power supply cord with safety plug (provided)

Power output: 1 x P-Con (gray), mounting version

Fuse: T 1 A Fuse replaceable

Lamp type: LED lamp

LED:

Spot 3 x high-power 4 W 4in1 QCL RGB/WW (homogenous color mix)

Multi beam effect 4 x high-power 3 W R/G/B/WW

Strobe effect 4 x high-power 1,5 W UV

Flash rate: 0 - 30 Hz

DMX channels: 6; 8; 11; 21; 25; 29

DMX input: 1 x 3-pin XLR (M) mounting version

DMX output: 1 x 3-pin XLR (F) mounting version

Cooling: Cooling fan

Control:

QuickDMX via USB (optional); DMX; Stand-alone; Sound to light via

Microphone; IR remote control; Wireless footswitch (optional)

Beam angle (1/2 peak): Spot 7°

Beam angle (1/10 peak): Spot 20°

Housing color: Black

Attachment system: TV spigot Ø 28mm

Dimensions:

Width: 1,11 m

Depth: 15 cm

Height: 41 cm

Weight: 10.50 kg

Noise classification: Class 2 (slight noise)

Laser

Laser class: Class 2M

Laser color: R/G

Laser module: R red 100 mW 650nm

G green 30 mW 532nm

Remote control

Battery: Button cell 3.0 V CR2025 lithium manganese built-in

1114 mm

410 mm

150 mm
