OPERATION

The built-in control panel of the unit features four operating buttons and a display which shows all operation

statuses. After connecting the unit to the mains it requires a short initialization process and is then ready for

operation. The display indicates the last operating mode. All settings remain stored even if the device is

disconnected from the mains. The device can be operated in stand-alone mode via the control board or in

DMX-controlled mode via any commercial DMX controller. The operating modes can be selected manually

by means of the display and the operating buttons.

Operating buttons

Button Function

Selects the operating mode or returns to the initial screen.

ENTER

Activates a value to be modified, enters a submenu or saves a value when

modifying.

Selects the next menu item or increases values when modifying.

DOWN

Selects the previous menu item or decreases values when modifying.

Menu structure

Default settings shaded

Display Submenu 1 Submenu 2 Description

DMX

Address

001

A001 – A512 Starting address

Mode

DMX

6CH

6-channel mode (Starting address 001 – 507)

10CH

10-channel mode (Starting address 001 – 503)

18CH

18-channel mode (Starting address 001 – 495)

24CH

24-channel mode (Starting address 001 – 489)

25CH

25-channel mode (Starting address 001 – 488)

32CH

32-channel mode (Starting address 001 – 481)

Auto

Pro 00 - 20

Show program 0 - 20

Sp 00 – 90 - 99

Running speed slow > fast

Sound

Pro 00 - 20

Show program 0 - 20

Se 00 – 80 - 99

Microphone sensitivity 0-100%

Manual

Dimmer 000–255

Total brightness 0-100%

Red 000–255 Brightness Red, 0=off, 1-100%

Green 000–255 Brightness Green, 0=off, 1-100%

Blue 000–255 Brightness Blue, 0=off, 1-100%

CWhite 000–255

Brightness

Cold

hite

0=off, 1-100%

WWhite 000–255

Brightness

Warm

hite

0=off, 1-100%

W CTO 000–255

Color temperature (White)

W-Show 000–012

White show mode

(Program 1-12) 000=all LEDs off

W-Sp 000–99

Program speed slow > fast

W-Str 000–255

Strobe 000=off, slow > fast
