00147165.DOCX, Version 1.0
27/28
TECHNICAL SPECIFICATIONS
Power supply: 100-240 V AC, 50/60 Hz
Power consumption: 30 W
IP classification: IP65
Protection class: Protection class I
Power connection:
Mains input via IP T-Con (M) mounting version
Power supply cord with safety plug (provided)
Lamp type: LED lamp
LED:
1 x 40 W COB (chip-on-board) 2in1 BCL CW/WW
(homogenous color mix)
Color temperature: 2700K - 6000K adjustable
Equipment: Zoom manual; Focus manual
Gobos:
Outside diameter 37,5mm
Image diameter 28mm
Thickness 1.5mm
DMX channels: 1; 2; 3; 6
DMX input: 1 x 3-pin XLR (M) mounting version IP
Control: Stand-alone; Master/slave function; DMX; RDM; Light Captain
Beam angle (1/2 peak):
15
-
30°
- Article 40001705
25
-
50°
- Article 40001706
Color rendering index (CRI): 92 Ra
Housing color: Black
Attachment system: Mounting bracket
Display type: 4 digit 7-segment LED display
Dimensions:
Length: 34.5 cm
Width: 15.5 cm
Height: 28.5 cm
Weight: 4.50 kg
Accessories
EUROLITE TPC-10 Coupler, silver No. 59006856
EUROLITE Safety Bond A 3x600mm up to 5kg, silver No. 58010310
EUROLITE Gobo Holder for LED IP PFE-40 No. 40001704
EUROLITE Adapter Cable IP T-Con(m)/2xT-Con(f) No. 30235009
EUROLITE Adapter Cable DMX IP XLR 3pol(m)/2xIP XLR 3pol(f) No. 30227869
PSSO DMX cable IP65 3pin 7.5m black No. 3022783E
EUROLITE IP T-Con Connection Cable 3x1.5 3m No. 30247754
All information is subject to change without prior notice. © 17.05.2023
345 mm
155 mm
285 mm
