OPERATION
After connecting the device to the mains it is ready for operation. The operating modes can be selected by means
of the display and the control buttons. All settings remain stored even if the device is disconnected from the mains.
The device can be operated in stand-alone mode via the control board or in DMX-controlled mode via any
commercial DMX controller.
Press the MENU button to access and browse through the main menu. Press the ENTER button in order to select
the desired menu item. You can change the selection by pressing UP or DOWN. Confirm every selection by
pressing the ENTER button. The functions provided are described in the following sections.
Menu structure
Default settings shaded
Main Menu Sub menu Function
A001
001 - 512
Setting the DMX starting address
CHnL
Setting DMX Mode
1CH 1-Channel DMX Mode
2CH 2-Channel DMX Mode
3CH 3-Channel DMX Mode
6CH 6-Channel DMX Mode
Fail
DMX Lost Mode
Hold Most recent DMX value is held
Full All LEDs 100% on
Blnd LEDs switched off
dinn
Master Dimmer (Master Mode)
000 - 255 Total brightness 0 – 100%
Strb
Strobe (Master Mode)
S.00 - S.20 Increasing speed
Dimmer (Master Mode)
uL--
u.000 - u.255 WW increasing brightness 0 – 100%
cL--
c.000 - c.255 CW increasing brightness 0 – 100%
nodE
Dimmer speed (step response)
nod.0
Response characteristics of LEDs: No delay
nod.1
Response characteristics of halogen lamps,
fast
nod.2
Response characteristics of halogen lamps,
less fast
nod.3
Response characteristics of halogen lamps,
middle
nod.4
Response characteristics of halogen lamps,
slow
tEnP
t--- Inner temperature
UErn
xxx Software Version
rSEt
Restore factory settings
PnnF
Pulse-width modulation
0.6F / 1.2F / 2.0F / 4.0F /
12F / 24F
With this function, the PWM frequency of the LEDs can
be set: 600Hz, 1200Hz, 2000Hz, 4000Hz, 12000Hz,
24000Hz
Stand-alone mode
In stand-alone mode, the device can be used without controller. Disconnect the device from the controller and call
up the menu you want to use. Please refer to the instructions under Menu structure.
