00147165.DOCX, Version 1.0
16/28
USER MANUAL
LED IP PFE-40 CW/WW
15-30° or 25-50°
DANGER! Electric shock caused by short-circuit
Be careful with your operations. With a dangerous voltage you can suffer a dangerous electric shock
when touching the wires. Never open the housing.
Please read these instructions carefully before using the product. They contain important information for
the correct use of the product.
Every person involved with the installation, operation and maintenance of this device has to
- be qualified
- follow the instructions of this manual
- consider this manual to be part of the total product
- keep this manual for the entire service life of the product
- pass this manual on to every further owner or user of the product
- download the latest version of the user manual from the Internet
INTRODUCTION
Thank you for having chosen one of our products. If you follow the instructions given in this manual, we are sure
that you will enjoy this device for a long period of time.
Product features
Weather-proof spotlight (IP65), 40 W LED, variable color temperature, CRI >90, RDM
• 1 powerful LED 40 W COB (chip-on-board) 2in1 BCL CW/WW (homogenous color mix)
• Variable color temperature 2700 K - 6000 K
• 4 shutter blades
• Gobo holder for own gobos with an outside diameter of 37.5 mm, image diameter max. 28 mm and
thickness of 1.5mm, included in delivery
• Can be operated in 1; 2; 3; 6 CH mode
• Controlling by stand-alone; Master/slave function; DMX; RDM
• Strobe effect
• With a beam angle of 15° - 30° or 25° - 50°
• Very high color rendering index (CRI)
• With mounting bracket
• 4 digit 7-segment LED display
• Zoom manual; Focus manual
• Dimmer electronic; Dimmer speed (step response) adjustable; pulse-width modulation variable
• Preprogrammed in Light Captain
• Mains input and output (via Y-mains adapter cable) for power linking up to 8 units
