Eurolite LED IP Mega PIX Strobe 714 Swing handleiding

Verlichting

Eurolite

44 pagina's

PDF beschikbaar

Handleiding

00160417, Version 1.0

32/44

Auto

PROG Pr 01 – 10 – 45 Auto programs, 0 - 45

PROG-

Speed

Sp 01–08–16 Auto programs speed, slow > fast

Test Auto test

Option

DmxCHs

8CH 8-channel mode

9CH 9-channel mode

11CH 11-channel mode

12CH 12-channel mode

17CH 17-channel mode

18CH 18-channel mode

71CH 71-channel mode

Smooth ON/OFF Dimming behaviour

LCD inverse ON/OFF

Display reverse 180°,

Display normal, OFF

Back light ON/OFF

Display off after 45s, On,

Display always, OFF

Key Lock ON/OFF

Display is locked with

Press MODE ENTER together 3 times to unlock

Display is unlocked with OFF

Setting

Reset

Reset to factory settings, (press ENTER button)

English

English System language

INFO

Item No. Device no.

Ver. Vx.xx Current software version

Temp. Xx°C Internal temperature of the device

RDM

This device supports RDM (Remote Device Management), which makes remote control of devices

connected to the DMX bus possible. ANSI E1.20-2006 by ESTA specifies the RDM standard as an extension

of the DMX512 protocol. RDM simplifies device configuration as manual settings like adjusting the DMX

starting address are no longer needed. RDM is integrated in DMX without influencing the connections. The

RDM data is transmitted via the standard XLR pins 1 and 2 – new DMX cables are not necessary. RDM-

ready and conventional DMX devices can be operated in one DMX line. The RDM protocol sends own

packages in the DMX512 data feed and does not influence conventional devices. DMX splitters, however,

must support RDM. Which parameters can be called up via RDM depends on the RDM controller used.

Master/slave operation

Several devices may be interconnected (max. 12). Then all slave units can be synchronized and controlled

with the master unit without the need for a DMX controller. The devices must be set to the corresponding

operating modes.

1 Configure all slave units before connecting the master unit. Set the DMX starting address 001 for all

slave devices.

2 Connect the DMX output of the master unit to the DMX input of the first slave unit. Then connect the

DMX output of the first slave unit to the DMX input of the second slave unit, etc. until all units have been

connected in a chain. Make sure the master unit is the first in the chain. Do not connect a DMX controller

to the DMX input of the master unit.

3 Select the desired setting (Auto mode) at the master unit. The interconnected devices will now operate

synchronously.
