00066542, Version 1.6

14/16

Connection with the mains

Connect the device to the mains with the power plug. The occupation of the connection cables is as follows:

Cable

International

Brown Live L

Blue Neutral N

Yellow/Green

Earth

Attention! The earth has to be connected!

If the device will be directly connected with the local power supply network, a disconnection switch with a

minimum opening of 3 mm at every pole has to be included in the permanent electrical installation.

The device must only be connected with an electric installation carried out in compliance with the IEC

standards. The electric installation must be equipped with a Residual Current Device (RCD) with a maximum

fault current of 30 mA.

OPERATION

Remote control

The remote control is supplied with battery inserted.

A barrier foil between the battery and the battery contacts prevents the battery from being discharged during

storage. Prior to the first operation remove the foil from the battery support on the rear side of the remote

control. Otherwise operation of the remote control is not possible.

When actuating a button, always hold the remote control in the direction of the sensor. There must be visual

connection between the remote control and the sensor.

If the range of the remote control decreases (7 meters as a maximum), replace the

battery. For this purpose, on the rear side of the remote control press the small bar

with the groove to the right and at the same time remove the battery support.

For operation, one 3 V button cell type CR 2025 is required. When inserting, pay

attention that the positive pole of the button cell shows upwards in the support.

CAUTION!

Danger of explosion when battery is replaced improperly. Only replace by the same type. Please dispose of

old and used batteries properly. Batteries are hazardous waste and should not be disposed of with regular

domestic waste!

R G B W

FLASH

STROBE

FADE

SMOOTH

OFF ON

Color buttons

Brightness: Static color, 3 levels

LEDs on

LEDs off

Seven color fading and switching

White fading in and out

Seven color switching

Internal program

Seven color fading

Speed: Internal programs, 3 levels

Static color

Internal program
