OPERATION
After connecting the device to the mains it is ready for operation. The display indicates the last operating
mode. The operating modes can be selected by means of the display and the control buttons. All settings
remain stored even if the device is disconnected from the mains. The device can be operated in stand-alone
mode via the control board or in DMX-controlled mode via any commercial DMX controller as well as
wireless via QuickDMX with the optionally available EUROLITE QuickDMX USB Wireless
Transmitter/Receiver.
After you connected the effect to the mains, the LED CAT-80 Beam Effect starts running. During the Reset,
the motors are trimmed and the device is ready for use afterwards.
The main menu is accessed by pressing the MENU button. Browse through the menu by pressing the MENU
button. Press the ENTER button in order to select the desired menu. You can change the selection by
pressing UP or DOWN. Confirm every selection by pressing the ENTER button. The functions provided are
described in the following sections.
Menu structure
Main menu Sub menu Function
Set Address
001 – 506 Setting the DMX starting address
Mode Choice
Auto
Automatic show program
DMX
DMX mode
Sound
Sound controlled show program
Manu
000 – 255
Dimmer Total brightness 0-100%
000 – 009 No function
010 – 255
Strobe Effect slow > fast
Gobos
000 – 009
Open
010 – 019
Gobo1
020 – 029
Gobo2
030 – 039
Gobo3
040 – 049
Gobo4
050 – 059
Gobo5
060 – 069 Gobo6
070 – 079
Gobo7
080 – 089
Gobo8
090 – 098
Gobo9
099 – 255
Rainbow effect fast > slow
000 – 255
Flower Rotation slow > fast
000 – 255
Mirror Cylinder Rotation slow > fast
000 – 255
Horizontal Cylinder Movement
, gradual adjustment of the
mirror cylinder position from left to right
Sensitive
000 – 100 Microphone sensitivity with increasing sensitivity
Reset
Motor reset
The display shuts off after a few seconds of inactivity.
