8. SYSTEM SETTINGS

This mode allows you to change important system

settings for the controller.

Calling the System Settings

Fig. 8.1 Calling the system settings

Keep the button MENU for 2 seconds to call

the system settings.

• The display indicates the first menu item

“01.Patch fixture”.

Turn the pan wheel to browse the menu

items.

Press the button ENTER to select the

desired menu item.

Turn the pan wheel to change a setting and

confirm with ENTER.

Shortly press the button ESC to abort the

setting procedure and return to the main

menu level.

To save your settings and exit the system

settings, keep the button MENU pressed for 2

seconds.

The following adjustments are possible:

Indication Function

01. Patch fixture

DMX configuration

02. Reset factory Reset to factory settings

03. Delete all

Fixture patch

Delete all DMX address

assignments

04. Fade mode Fade function

05. RDM DMX

Address setup

RDM DMX address

assignments

06. Data backup Data backup

07. Data load Data import

08. Send fixture

Update file

Firmware update

09. Black-out mode Blackout function

This menu item is covered in chapter 6.

This function is not available.

Reset factory [Reset to factory

settings]

Here you can reset the controller to factory

setting.

Call the menu item with the pan wheel and

confirm with ENTER.

Select the setting [YES] with the pan wheel

and confirm with ENTER.

• The display shortly indicates ”Reset factory

Please wait G.“ and then “OK“ as soon as

the factory settings are loaded.

Delete all Fixture patch [Delete all

DMX address assignments]

All address assignments and control channel

options made can be deleted and reset to the

presettings.

Call the menu item with the pan wheel and

confirm with ENTER.

Select the setting [YES] with the pan wheel

if a reset is to be made. Confirm with

ENTER.

• The display shortly indicates “SAVE OK“ and

returns to the main menu level.

Fade mode [Fade function]

The fade function can be assigned to all control

channels or only to the pan and tilt wheels.

Call the menu item with the pan wheel and

confirm with ENTER.

Use the pan wheel to select the setting [ALL

CHANNELS] if the fade function is possible

for all control channels or select [ONLY

PAN/TILT] if it is only possible for the pan

and tilt wheels. Confirm with ENTER.

• The display shortly indicates “SAVE OK“ and

returns to the main menu level.

01.Patch fixture
