Operation with the IR remote control IR-7

The device must be activated for remote control. For this, set menu item IrYE to IrYE. When actuating a

button, always direct the remote control towards the sensor (see Description of the Device). There must be

no obstacles between remote control and the sensor.

Button Function

BLACKOUT

Press once: LEDs off

Press again: return to the last mode.

AUTO

Automatic mode; press the AUTO key repeatedly to

switch through auto programs (CC, CP);

speed selection with (+)/(‒)

Quick speed is adjusted by pressing the SPEED button

repeatedly.

SOUND

Sound control (SUn); microphone sensitivity with (+)/(‒)

STROBE

Strobe effect for automatic mode, sound control and

preset colors (0-9); flash rate setting with (+)/(‒);press

STROBE button again to stop the strobe effect

SPEED

Switches the values of the auto programs (CC, CP, dE)

between 00 and 99

Quick speed selection is adjusted by pressing the

SPEED button repeatedly. (speed values :20-50-80-99)

SENSITIVITY

DMX/%

No function

MANUAL

R/G/B/W/A/UV

Activate preset colors manually, two modes:

Mode A:

1. Press the MANUAL button, then press R, G, B, W, A

or UV to choose the desired color.

2. Press the color once for 20% brightness;

3. Press a 2nd time for 40% brightness;

4. Press a 3rd time for 60% brightness;

5. Press a 4th time for 80% brightness;

6. Press a 5th time for 100% brightness

Mode B:

1. Press the MANUAL button, then press R, G, B, W, A

or UV to choose the desired color.

2. Press (+) or (‒) to either increase or decrease the

brightness.

FADE

Color fade (dE), use (+)/(‒) to set the FADE program

speed

0-9

Preset colors, intensity setting with (+)/(‒)

• The remote control is supplied with a battery inserted. An insulating foil between the battery and the battery

contacts prevents the battery from being discharged during storage. Prior to the first operation remove the

foil from the battery support on the rear side of the remote control. Otherwise operation of the remote

control is not possible.

• If the range of the remote control decreases, replace the battery. For this purpose, on

the rear side of the remote control press the small bar with the groove to the right and

at the same time remove the battery support. For operation, one 3 V button cell type

CR 2025 is required. When inserting, pay attention that the positive pole of the button

cell shows upwards in the support.

• Remove the battery from the remote control as a precaution if the device is not used for a longer period of

time.
