EN 27
EN
TECHNICAL SPECIFICATIONS
Technical data
Hob AKI671
--
AKI680
--
/ AKI380
--
Product type Built-in Built-in
Dimensions
Width 700 mm 800 mm
Depth 520 mm 520 mm
Height 230 mm 230 mm
Power supply voltage/frequency
~380-415V 50/60Hz
~220-240V 50/60Hz
~380-415V 50/60Hz
~220-240V 50/60Hz
Power 7620 W 7620 W
Weight 21 kg 23 kg
Extractor unit
Airflow max* - Exhaust installation 500 m
3
/u 500 m
3
/u
Noise max* - Exhaust installation 65 dBA 65 dBA
Extractor unit power 220 W 220 W
* Maximum speed (boost excluded)
Information according regulation (EU) 66/2014
Measurements according EN60350-2
Model identification AKI671
--
AKI680
--
AKI380
--
Type of hob Induction hob Induction hob
Number of electric cooking zones and/or areas 4 4
Heating technology Induction cooking
zones and cooking
areas
Induction cooking
zones and cooking
areas
For non-circular cooking zones or areas: lenght
and width of useful surface area per electric heated
cooking zone or area
210 x 190 mm
Energy consumption per cooking zone or area
calculated perkg (EC
electric hob
) in Wh/kg
210x190 mm:
184.0 Wh/kg
Ø200 mm:
194.8 Wh/kg
Ø160 mm:
168.2 Wh/kg
Ø200 mm:
194.8 Wh/kg
Ø160 mm:
168.2 Wh/kg
Energy consumption for the hob calculated per kg
(EC
electric hob
) in Wh/kg
182.7 180.75
