EFL60W30V1/EFL120W30V1/EFL200W30V1/EFL60W40V1/EFL120W40V1/EFL200W40V1
V. 02 – 22/09/2020 9 ©Velleman nv
5. Care and Maintenance
Care
• This appliance does not need any particular maintenance. However, regularly check the
mounting installation and external flexible cable or cord. Do not use the appliance if there
is visible damage.
Cleaning
• Regularly clean the protection shield screens to optimize the light output.
• The frequency of cleaning depends on the operating environment: wet, smoky or
particularly dirty surroundings can cause more accumulation of dirt on the optics of the
appliance.
• Before cleaning, switch off the appliance and disconnect from the mains. Use a lint-free
damp cloth for cleaning. Never use solvents or alcohol for cleaning. Always dry the parts
carefully.
Storage
• Store the appliance in its original package in a dry and clean place.
6. Technical Specifications
EFL60W30V1/EFL60W40V1
mechanical impact .................................................................................................... IK08
electrical data
power LED module ................................................................................ 96 x SMD LEDs
total nominal power ............................................................................................ 60 W
nominal voltage driver ............................................................... 100-240 V~, 50/60 Hz
power factor ....................................................................................................... 0.95
energy consumption ............................................................................. 61 kWh/1000 h
recommended power supply ....................................................... Mean Well ELG-75-48A
light technical data
colour
EFL60W30V1 ...................................................................................... warm white
EFL60W40V1 .................................................................................... neutral white
colour temperature
EFL60W30V1 ............................................................................................ 3000 K
EFL60W40V1 ............................................................................................ 4000 K
beam angle .......................................................................................................... 90°
luminous flux ................................................................................................. 8500 lm
colour rendering index .........................................................................................> 80
starting time ................................................................................................... < 0.5 s
warm-up time (60 %) ......................................................................................... < 1 s
lifespan
nominal lifetime ............................................................................................ 50 000 h
number of switching cycles ............................................................................... 25 000
cable type .......................................................................................... H07RN-F 3G1.0mm²
cable length ............................................................................................................ 1.5 m
dimensions (W x H x D) ......................................................................... 289 x 69 x 364 mm
weight ...................................................................................................................3850 g
t
a
........................................................................................................................... 25 °C
t
x
........................................................................................................................... 43 °C
t
a
Environmental temperature.
t
x
Steady-state housing temperature.
