Ethernet Adapter
10 User’s Manual
Connecting Remote Wake-Up Cable
This is an optional function. Proceed with the installation only
when your PC supports this Remote Wake-Up and you wish to
make use of this function. For more information, please check the
User’s Guide for your Motherboard.
Step 1: Make sure the power to the PC is off.
Follow Step 1~3 in previous section.
Step 2: Check if the Ethernet Adapter is properly installed in a PCI slot.
Step 3: Prepare a Remote Wake-Up cable. Connect the cable from Ethernet
Adapter to motherboard connector. Refer to Figure 2 below for details.
Step 4: Replace the PC cover then.
Step 5: Proceed to “Connecting to Your Network” Section.
Connect Remote Wake-Up cable from Ethernet Adapter to motherboard connector.
Plug in Remote Wake-Up cable to connector on Ethernet Adapter.
Figure 2: Connecting Wake-Up cable
