ED3541 Industrial Ethernet Extender User Guide
Quick Start Guide
The following procedure enables advanced users to get their Hardened Ethernet Extender up and
running in the shortest possible time. For detailed installation instructions, refer to the sections in the
right column below.
Step
Description
For Reference, See…
1.
Find a Location for the Hardened Ethernet Extender
Set the Hardened Ethernet Extender on a flat surface, Wall-mount, or DIN-Rail mount.
“Preparing the Site” (page 15)
2.
Connect to the 10/100 Mbps Ethernet Port
Connect one end of a Category 5 or better Ethernet cable to the Ethernet port of a computer,
printer, network storage, or other network device.
Connect the other end to a 10/100 Mbps RJ-45 port on the Hardened Ethernet Extender.
“10/100 Mbps RJ-45 Port" (page 12)
and
“Connecting to the 10/100 Mbps RJ-45
Port” (page 16)
3.
Connect to the Ethernet Extender Port
Insert the voice grade copper wire between one pair of Ethernet Extenders via Ethernet
Extender port (RJ-11 connector or Terminal Block).
4.
Power On
Connect the DC power cord to the plug-able terminal block on the Ethernet Extender, and then
plug it into a standard DC outlet.
Connect the ground connection from the terminal block to the grounding surface.
Wait for the Hardened Ethernet Extender to complete its Power On Self Test.
Confirm that the LEDs for ports connected to a device are green. If not, replace the Ethernet
cable, and then check the port LED again.
“Applying DC Power” (page 17)
