24
ED3501 Industrial Ethernet Extender User Guide
Interface
Specification
Description
Ethernet Port:
One 10/100BASE-TX port
Ethernet Extender Port:
One RJ-11 and Terminal Block port
DIP Switch
DIP Switch 1: Auto/Local mode
DIP Switch 2: Symmetric/Asymmetric mode
DIP Switch 3: Performance/Standard mode
LED Indicators:
Per unit: Power Status
Ethernet port: Link/Activity, Speed
Ethernet Extender port: Link/Activity, Per, RMT, LOC, SYM, ASM, Line Speed
The data rates will vary according to the quality of the connected cable. The information
below is only for reference of applications.
Distance (m)
Data Rate (Mbps)
300
100
400
80
600
60
800
40
2600
1
This distance/data rate information is measured according testing standard in EtherWAN
laboratory. The actual installation will be affected by the quality of copper wire and the impact
of noise disturbance. The connection speed will be affected.
NOTE: After making changes to the position of any DIP switch, the Ethernet Extender must be
rebooted for the new settings to take effect.
