Je bekijkt pagina 27 van 60
V. REMOVING THE DUST CONTAINER AND FILTERS
Caution
– Maximum suction performance can be achieved when the filters are clean and the
dustbag is empty.
–
Every time you empty the dust container, we recommend that you also clean the filters.
– When you are vacuuming very fine dust, the filter pores might get clogged. This
reduces the air flow and the suction performance deteriorates. In such a case, the
filters need to be cleaned even though the container is not full yet.
DUST CONTAINER REMOVAL
When taking out the dust container B follow the procedure indicated in Fig. 4. Dispose of
dirt contained in the dust container with regular household waste. An emptied and cleaned
container is to be put back into the vacuum cleaner in reverse order.
INPUT FILTER REPLACEMENT
To remove the input filter, follow the procedure indicated in Fig. 4. To fit a new input filter
in the vacuum cleaner, proceed in reverse order.
OUTPUT FILTERS REPLACEMENT
To remove the input filter, follow the procedure indicated in Fig. 3. To fit a new output filter
in the vacuum cleaner, proceed in reverse order.
VI. CLEANING AND MAINTENANCE
Treat surface of the appliance with asoft and damp cloth, do not use coarse and aggressive
detergents!
Accessories
After any vacuuming it is recommended to check visually the brushes or collectors
for possible impurities. If there are some impurities, remove them.
Cleaning the TURBO nozzle C3 (Fig. 8)
Cut the threads and hairs with scissors. Turn on the vacuum cleaner. The cleaner vacuums
the cut hairs and threads. In case hairs or threads got tangled up around the attachment of
the brush cylinder and cannot be removed with the above-mentioned steps, it is necessary
to remove them with a suitable tool (e.g. tweezers). For simpler and more comfortable
maintenance, remove the upper cover by releasing the locking latches on the sides. At the
same time, make sure no dirt is stuck on the inner side of the nozzle (i.e. turbine). Release
the two arrest latches on the bottom side of the nozzle in the direction of the arrow and
remove the cover. Clean the space with a suitable tool (e.g. tweezers). Insert the covers
back into the nozzle reversely and close it with by folding it up (you hear an audible click).
Dust container
Clean the dust container with a wet
cloth.Allowallthepartstodryoutproperlybeforere-use.
Input and output filters
Rinse the filter A12, B4, B5, B7 under running water. Allow them to dry out properly before
their re-use. Shake out the HEPA filter A11 gently, or blow it out. If the HEPA filter is very
dirty, you can rinse it under running lukewarm water. Allow it to dry out properly.
EN
27
