– Use the charger in a room only.
– The adaptor supplied with this appliance is intended for this appliance only, do not use
it for other purposes.
– The power cord must not be damaged with sharp or hot objects, open fire, it must not
be sunk into water or bent over sharp edges.
For trouble-free operation of the vacuum cleaner, please use
the tested micro-filters recommended by the producer.
II. EQUIPMENT AND ACCESSORIES (Fig. 1-12)
A – vacuum cleaner
A1 – ON/OFF button
A2 – output HEPA filter
A3 – HEPA filter output cover
A4 – handle
B –
LED control panel (relevant for ETA2232)
B1 – Button "-/+“ - Adjustment of suction
power (ECO / BOOST / TURBO)
B2 – Suction power indicator lamps
C –
LED control panel (relevant for ETA3232)
C1 – button "+" - increasing suction power
C2 – button "-" - lowering suction power
C3 – button "AUTO" - automatic increasing
suction power for heavy dirt
C4 – indicator lamp - rotation brush blocked
C5 – indicator lamp - automatic suction
power increasing
C6 – indicator lamp - suction blocked
(clogging)
C7 – indicator lamp - suction power
C8 – indicator lamp - heavy dirt (sucked
dirt) in "AUTO" mode
D – dust container
D1 – container lock button
D2 – separator
D3 – upper separator plastic component
D4 –HEPA filter (input)
D5 – folding handle
E – battery
E1 – battery lock button
E2 –
operation indicator lamp, battery charging
E3 – charging connector
F – metal suction tube with a joint
F1 – joint
F2 – joint lock
F3 – tube lock button
G – floor nozzle with rotation brush
G1 – floor nozzle lock button
G2 – LEDs illuminating the space in front
of the vacuum cleaner
G3 – removable brush
G4 – brush release button
H – small direct-drive turbo brush
H1 – nozzle lock button
H2 – brush lock button
H3 – removable brush
I – brush + pillow nozzle 2 v 1
I1 – adapter lock button
I2 – brush lock button
J – telescopic crevice nozzle
J1 – adapter lock button
J2 – sliding lock button
K – mopping adapter
K1 – mopping adapter locking button
K2 – water tank (490 ml)
K3 – water tank locking button
K4 – filling orifice plug
K5 – moistening on/off switch
K6 – plastic mop pad cover
K7 – mop pad (2x)
L – adapter
M – plastic wall charging holder
M1 – screw holes
M2 – charging connector
N – screws
O – wall plugs
EN
29 / 63
