EN
27 / 5526
II. EQUIPMENT AND ACCESSORIES (Fig. 1)
A – vacuum cleaner
A1 – ON/OFF button
A2 – operation signal lights and charging
lights
A3 – handle
B – dust container
B1 – HEPA filter
B2 – separator
B3 – container lock buttons
C – accessories
C1 – crevice nozzle
C2 – brush
C3 – electric turbo brush
C4 – removable brush
C5 – removable brush arrest
C6 – arresting lock
D – extension adapter
D1 – ON/OFF button.
D2 – suction power control
D3 – foldable part with handle
D4 – foldable part lock
D5 – vacuum cleaner lid lock button
E – floor nozzle with rotation brush
E1 – floor nozzle lock button
E2 – removable brush
E3 – brush lock
E4 – LEDs illuminating the space in front
of the vacuum cleaner
F – mop attachment
F1 – universal mop pad
F2 – mop pad for fine cleaning
F3 – mop pad for dirt particles
F4 – filling openings
G – charging stand
G1 – lower part
G2 – support
G3 – support lid lock button
G4 – hole for fixing on the wall
G5 – charging port
G6 – space for small accessories
(crevice nozzle, brush)
H – adapter
III. VACUUM CLEANER PREPARATION
Remove all packing material, take out the vacuum cleaner and the accessories. Remove all
possible adhesion foils, stick-on labels or paper from the appliance.
VACUUM CLEANER ASSEMBLY
When assembling the vacuum cleaner, follow the procedure indicated in Fig. 1, 2. Select
appropriate accessories (Fig. 8) depending on the required use (hand vacuum cleaner / stick
vacuum cleaner / mop). For disassembly, proceed the other way round and release the locks.
CHARGING THE ACCUMULATOR
Turn the vacuum cleaner off prior to charging!
Place the vacuum cleaner in the
extension attachment and then in the charging base G. Connect the adaptor to the
charging connector G5 and plug it to the mains.
The accumulator has to be charged at
least for 8 hours prior to the first use. After that, the standard charging time is approx.
4-6 hours. The status and progress of charging is indicated by indicator A2.
